Industry Norms
Test Results
Thickness
1.0mm mm (± 10%)
1.0mm (± 0.05%)
Resistance to surface wear
= 350 (revolutions)
> >500 (revolutions)
Resistance to immersion in boiling water Mass increase (%)
10% (Max)
6.0% (Max)
Resistance to immersion in boiling water Thickness increase (%)
11.8% (Max)
7.0% (Max)
Resistance to dry heat 180º C
Should pass test
Passed
Dimensional stability at deviated temperature Lengthwise (%)
0.55% (Max)
0.35% (Max)
Dimensional stability at deviated temperature Crosswise (%)
1.025% (Max)
0.75% (Max)
Dimensional stability at 20º C Lengthwise (%)
0.375% (Max)
0.275% (Max)
Dimensional stability at 20º C Crosswise (%)
0.6% (Max)
0.48% (Max)
Resistance to impact by small diameter ball
20N (Min)
25 N (Min)
Resistance to cracking
Should pass test
Passed
Resistance to scratching
2N (Min)
3N (Min)
Resistance to staining
Should pass test
Passed
Resistance to colour change In Xenon light
Should pass test
Passed
Resistance to colour change In Enclosed Carbon ARC light
Should pass test
Passed
Resistance to cigarette burns
Should pass test
Passed
Resistance to steam
Should pass test
Passed
Appearance
No ABC Defects
No ABC Defects
Specific gravity gm/c.m3
N/A
1.40 (Min)
